High-Intensity Magnetic Liquid Traps

Force Magnetic Solution emerges as a preeminent manufacturer and supplier of large-scale High-Intensity Magnetic Liquid Traps in China. Drawing from our profound expertise in magnetic separation technology, we excel in delivering customized solutions tailored to the specific requirements of our clients. Our products have gained a solid foothold in the global market, testament to their unwavering reliability and exceptional efficiency.

As the professional manufacturer, we would like to provide you High-Intensity Magnetic Liquid Traps. The Force Magnetic Solution's High-Intensity Magnetic Liquid Traps provide an efficient solution for eliminating iron particles and stainless powder from wet or liquid substances. Utilizing high-performance neodymium magnets, these separators are precision-engineered to meet even the most stringent magnetic separation requirements. Additionally, innovative design of separator magnetic facilitates easy installation and maintenance, making them a trusted option for a diverse range of industrial applications.

Working Principle

The High-Intensity Magnetic Liquid Traps uses a strong permanent magnetic field to separate iron impurities from the flowing fluid. As the fluid enters the equipment, it flows through a strong magnetic field generated by permanent magnets. During this process, iron impurities are attracted to the magnetic components, while the clean fluid continues to flow through the pipeline and is discharged. With the use of permanent magnets, the equipment operates without external power supply, ensuring stable and reliable operation. There is no automatic cleaning system, so when iron impurities accumulate to a certain level, the magnetic components need to be manually cleaned to maintain efficient operation.

Magnetic Filter

The Force Magnetic Solution's High-Intensity Magnetic Liquid Traps boast several notable features:

1.Flexibility in customization: The magnetic separators of liquids' inlet and outlet can be tailored to OEM specifications, ensuring seamless integration into diverse systems.

2.Versatile magnetic tube options: A wide array of magnetic tube choices is available, allowing users to select the most suitable option based on their specific separation needs.

3.Food-grade compliance: The comprehensive shield design guarantees adherence to the strictest food-grade processing standards, ensuring safety and hygiene in food-related applications.

4.Easy cleaning: A double tubing configuration is provided for convenient cleaning, reducing maintenance efforts and downtime.


Product schematic diagram

Magnetic Filter

Performance Parameters
Model Performance
(GS)
Magnetic bar qty (pc) Materials A
(mm)
A
(mm)
C D
(mm)
E
(mm)
FNS-GD-159 10000 8 201#/304# 200 DN65 DN65 Φ159 Φ25*190
FNS-GD-219 12000 5 201#/304# 200 DN80 DN80 Φ219 Φ32*190
FNS-GD-250 10000 10 201#/304# 200 DN159 DN159 Φ250 Φ25*190
FNS-GD-300 10000 13 201#/304# 350 DN100 DN100 Φ300 Φ25*340
Magnetic ferrous traps specification can be customized

Product Photograph

Professional quality exquisite craftsmanship

Magnetic Filter

Detail Display

Magnetic Filter

1.Customization of pipeline dimensions based on customer docking.

Magnetic Filter

2.According to the pressure level, clamps and corrugated hole types can be selected.

Magnetic Filter

3.The inside and outside of the cylinder can be treated with mirror or spray coating.

Magnetic Filter

4.Easy to clean form can be adopted according to on-site requirements

Factory shooting

Exterior scene

Exterior scene

Workshop 1

Workshop 1

Workshop 2

Workshop 2

Workshop 3

Workshop 3

Office

Office

Warehouse

Warehouse

Company Honors

● High-Tech Enterprise
● Innovative Small and Medium-Sized Enterprise
● Certified ISO9001 Quality Management System
● Member of the Foshan Entrepreneurs Association
● Member of the Nanhai High-Tech Zone Chamber of Commerce
● Member of the Foshan Intellectual Property Association
● Certified China Online Marketing Credit Enterprise
● Outstanding Supplier at the 7th National Quartz Conference
● Dozens of Patented Products Available for Your Selection

Company HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany HonorsCompany Honors
Company HonorsCompany Honors

Applications

Garbage sorting

Garbage sorting

Pharmaceutical industry

Pharmaceutical industry

Quartz sand

Quartz sand

Mining equipment

Mining equipment

Energy and Environmental Protection

Energy and Environmental Protection

Sewage disposal

Sewage disposal

Battery material

Battery material

Food industry

Food industry

Rubber and plastic materials

Rubber and plastic materials
